Laboratory Electrical Test Programmable Paint Type 150L Humidity Temperature Chamber

Name: Laboratory Electrical Test Programmable Paint Type 150L Humidity Temperature Chamber
Brand: HAIDA
Price: 1 USD

Laboratory Electrical Test Programmable Paint Type 150L Humidity Temperature Chamber Manufactures

Brand Name : HAIDA

Model Number : HD-E702-150

Certification : CE,,ISO

Place of Origin : China

MOQ : 1 set

Price : Negotiation

Payment Terms : L/C, T/T, D/A, D/P, Western Union, MoneyGram

Supply Ability : 300 sets per month

Delivery Time : 20 days after order confirmed

Packaging Details : each set protected with resin fiber and PP film, then put into Strong wooden case with operation man

Internal dimension (W*D*H) : 500*500*600mm

External dimension (W*D*H) : 700*1280*1480mm

Temperature range : -70~+150℃

Humidity fluctuation : ±2.5%RH

Humidity uniformity : 3%RH

Cooling speed : 1℃/min in average (without loading)

Contact Now

Laboratory Electrical Test Programmable Paint Type 150L Humidity Temperature Chamber

APPLICATIONS

High and low temperature test box is suitable for military, aerospace products, information electronic instruments, materials, electrical, electronic products, automotive electronic components in high and low temperature environment, testing its performance indicators.

Characteristics of control system

Temperature fluctuation: ±0.5℃, temperature uniformity: ±2℃.

Temperature overshoot is less than or equal to 3℃.

Temperature recovery time is less than or equal to 5 minutes.

Standard

GB/T 10589-2008 Specifications for low temperature test chambers

GB/T 10592-2008 Specification for low/high temperature test chambers

GB/T 11158-2008 Specifications for high temperature test chambers

GB/T5170.2-2008 Inspection methods for environmental testing equipments for electric and electronic products.

Temperature testing equipments　　

Laboratory Electrical Test Programmable Paint Type 150L Humidity Temperature Chamber

HUMIDITY RANGE

Laboratory Electrical Test Programmable Paint Type 150L Humidity Temperature Chamber

STANDARD FEATURES

Model	HD-E702-150-7
Internal dimension (WDH)	500500600mm
External dimension (WDH)	70012801480mm
Temperature range	-70~+150℃
Temperature fluctuation	±0.5℃
Temperature uniformity	2℃
Humidity range	20~98%RH (Refer Image below)
Humidity fluctuation	±2.5%RH
Humidity uniformity	3%RH
Cooling speed	1℃/min in average (without loading)
Heating speed	3℃/min in average (without loading)
Internal chamber material	SUS#304 stainless steel, mirror finished
External chamber material	Stainless steel
Cooling method	Air cooling
Controller	LCD touch screen, programmable control temperature and humidity Can set different parameter for cyclic test
Insulation material	50mm high density rigid Polyurethane foam
Heater	Explosion-proof type SUS#304 stainless steel fins radiator pipe heater
Compressor	France Tecumseh compressor x 2sets
Lighting	Heat resistance
Temperature sensor	PT-100 dry and wet bulb sensor
Observation window	Tempered glass
Testing hole	Diameter 50mm, for cable routing
Sample tray	SUS#304 stainless steel, 2pcs
Safety protection device	Protection for leakage Over-temperature Compressor overvoltage and overload Heater short circuit Water shortage
